API 608 Floating Ball Valve, ASTM A182 F316, 1-1/2 IN, 800 LB
Key Specifications / Features
Model No.: WV-240108-FBV-01 Hits: 8
Welcome to our advanced API 608 Floating Ball Valve Plant, where precision meets performance. This valve, meticulously crafted as per API 608 standards, features a 1-1/2 inch size and Class 800 LB rating, ensuring reliability in demanding applications. Constructed from high-grade ASTM A182 F316 stainless steel, it offers corrosion resistance and durability.
Request a quoteTags:
Detail Information
Design Standard: API 608
Body Material: ASTM A182 F316
Nominal Diameter: 1-1/2 Inch, DN40, 40MM
Pressure: Class 800 LB, CL800, PN150
End Connection: Three-Piece Threaded, Welded, Flanged Ends
Face To Face: Factory Standard
Test And Inspection: API 598
Construction: Full Bore
Feature: Threaded Floating Type Metal Seat Ball Valve, Bidirectional design with preferred direction, Oversized stem design, Scraper seat design, Inconel? spring design, Live-loading design, Anti-static design, Anti-blowout stem design, ISO 5211 mounting pad, Fire safe design
Product Range
Body Material: ASTM A216 WCB, ASTM A351 CF8M
Nominal Size: 1/2-2 Inch (DN15-DN50)
Pressure Rating: ASME Class 600 LB, Class 800 LB, Class 1500 LB, Class 2500 LB
End Connections: Threaded, Socket Weld, Butt Weld, Flanged
Temperature Range: -20℉ - 661℉ (-29℃ - 350℃), higher temperature on request.
Flanged Face-to-face Dimensions: ASME B16.10, EN 558 Series 5, Series 14
Flanged Dimensions: ASME B16.5, EN 1092-1
Body Pressure Test: ASME B16.34, API 598
Seat Leakage Test: ANSI/FCI70-2 Class V in standard, Class VI in option.
Casting: MSS-SP-25, MSS-SP-55
Body Material: ASTM A182 F316
Nominal Diameter: 1-1/2 Inch, DN40, 40MM
Pressure: Class 800 LB, CL800, PN150
End Connection: Three-Piece Threaded, Welded, Flanged Ends
Face To Face: Factory Standard
Test And Inspection: API 598
Construction: Full Bore
Feature: Threaded Floating Type Metal Seat Ball Valve, Bidirectional design with preferred direction, Oversized stem design, Scraper seat design, Inconel? spring design, Live-loading design, Anti-static design, Anti-blowout stem design, ISO 5211 mounting pad, Fire safe design
Product Range
Body Material: ASTM A216 WCB, ASTM A351 CF8M
Nominal Size: 1/2-2 Inch (DN15-DN50)
Pressure Rating: ASME Class 600 LB, Class 800 LB, Class 1500 LB, Class 2500 LB
End Connections: Threaded, Socket Weld, Butt Weld, Flanged
Temperature Range: -20℉ - 661℉ (-29℃ - 350℃), higher temperature on request.
Flanged Face-to-face Dimensions: ASME B16.10, EN 558 Series 5, Series 14
Flanged Dimensions: ASME B16.5, EN 1092-1
Body Pressure Test: ASME B16.34, API 598
Seat Leakage Test: ANSI/FCI70-2 Class V in standard, Class VI in option.
Casting: MSS-SP-25, MSS-SP-55
