Design Standard: API 6D
Body Material: ASTM A351 CF8M
Nominal Diameter: 3 Inch, DN80, 80MM
Pressure: Class 300 LB, CL300, PN50
End Connection: Two-Piece Flange RF
Face To Face: ASME B16.10
Test And Inspection: API 598
Construction: Full Bore
Feature: Floating Type Metal Seat Ball Valve, Highly precise machining, Spring-loading design, Various seat designs, Oversized stem design, Larger ball design, Anti-jam design, ISO 10497 Fire Safe Test certificated, Anti-static design, Anti-blowout stem design
Product Range
Body Material: ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M
Nominal Size: 1/2-8 Inch (DN15-DN200)
Pressure Rating: JIS 10, JIS 20K, ASME Class 150 LB, Class 300 LB, Class 600 LB, DIN PN16, PN40, PN100
End Connections: RF
Temperature Range: -20 - 932℉ (-29 - 500℃), higher temperature on request
Face-to-face Dimensions: JIS B2002, ASME B16.10, EN 558 Series 5, Series 14, Series 15
Flanged Dimensions: JIS B2220, ASME B16.5, EN 1092-1
Body Pressure Test: JIS B2003, ASME B16.34, API 598, EN 12266-1
Seat Leakage Test: ANSI/FCI70-2 Class V in standard, Class VI in option
Casting: MSS-SP-25, MSS-SP-55
Fire Safe Design: Certificated according to ISO 10497
