API 608 Ball Valve, ASTM A182 F316, 3 Inch, Class 800 LB, SW
Key Specifications / Features
Model No.: WV-240229-FSBV-05 Hits: 1
Operating from our state-of-the-art facility in China, we specialize in manufacturing ASTM A182 F316 ball valves to the highest standards. Our three-piece ball valves are engineered for excellence, complying with API 608 and API 607 specifications. With a generous size of 3 inches (DN80) and a robust Class 800 LB rating, these valves are designed to withstand high-pressure environments.
Request a quoteTags:
Detail Information
Standard: API 608, API 607, API 6D, BS 5351
Material: ASTM A182 F316
Size: 3 Inch, DN80
Pressure: Class 800 LB, PN130
End Connection: SW
Operating: Lever
Test & Inspection: API 598
Face to Face: ASME B16.10
Suitable Medium: Water, Natural Gas, Oil and some corrosive liquid
Working Temperature: -29℃ – 180℃
Material: ASTM A182 F316
Size: 3 Inch, DN80
Pressure: Class 800 LB, PN130
End Connection: SW
Operating: Lever
Test & Inspection: API 598
Face to Face: ASME B16.10
Suitable Medium: Water, Natural Gas, Oil and some corrosive liquid
Working Temperature: -29℃ – 180℃
