Bolted Bonnet Globe Valve, ASTM A182 F22, 3/4 IN, 800 LB, SW

Bolted Bonnet Globe Valve, ASTM A182 F22, 3/4 IN, 800 LB, SW

Key Specifications / Features

Model No.: WV-231223-AGBV-01 Hits: 1

Explore superior quality with our Bolted Bonnet Globe Valve, crafted from Forged Steel ASTM A182 F22. Designed to meet API 602 standards, this valve boasts a robust 3/4-inch build, ideal for applications demanding precision and reliability. Operating seamlessly at Class 800 LB, DN20, and PN130, this valve ensures optimal performance. Its user-friendly Handwheel Operation adds convenience to your workflow.

Request a quote

Detail Information

Valve description:
Globe valve, forged steel, F22, SW.
Design: API 602.
Body: ASTM A182 F22
Nominal size: 3/4 Inch.
Nominal class: 800 LB.
End Connection: SW
Operation: Handwheel
Face to face: MFG'S.
Test and inspection: API 598.

Product Range:
Body material: Forged steel.
Normal diameter: 1/2 -3 Inch (DN15 - DN80).
End connection: BW, SW.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +400℃.

Technical parameters and characteristics
Product Globe valve.
Nominal diameter 1/2 Inch - 3 Inch.
Design temp. Down to -29℃.
Design pressure Class 150 - 2500 LB.
Material Forged steel.
Design standard API 602.
Face to face MFG'S.
Operation Handwheel
Connection end BW, SW.
Test standard API 598.
Package Plywood
Application The oil and gas industry
