API 600 Gate Valve, ASTM A216 WCB, 4 Inch, Class 150 LB, RF
Key Specifications / Features
Model No.: WV-231228-AGV-06 Hits: 70
Welcome to our esteemed API 600 Gate Valve Plant in China, where precision engineering meets excellence in fluid control. Our 4-inch gate valve, meticulously crafted from Carbon Steel ASTM A216 WCB, adheres to the API 600 standard. With a Class 150 LB rating and DN100 specifications, this valve is designed for optimal performance in various applications.
$0.01In stock(Price depends upon negotiation)
Request a quoteTags
Detail Information
Design: API 600.
Body: ASTM A216 WCB
Nominal size: DN100, 4 Inch.
Nominal class: PN16, 150 LB.
End Connection: RF.
Face to face: ASME B16.10.
Test and inspection: API 598.
Product Range：
Body material: Carbon steel.
Normal diameter: DN50 - DN800.
End connection: BW, Flanged.
Pressure range: 150 - 2500 LB (PN16 - PN250).
Working temperature: -29℃ - +429℃.
Technical parameters and characteristics
Body: ASTM A216 WCB
Nominal size: DN100, 4 Inch.
Nominal class: PN16, 150 LB.
End Connection: RF.
Face to face: ASME B16.10.
Test and inspection: API 598.
Product Range：
Body material: Carbon steel.
Normal diameter: DN50 - DN800.
End connection: BW, Flanged.
Pressure range: 150 - 2500 LB (PN16 - PN250).
Working temperature: -29℃ - +429℃.
Technical parameters and characteristics
| Product | Gate valve. |
| Nominal diameter | DN50 - DN800. |
| Design temp. | Down to -29℃. |
| Design pressure | Class 150 - 2500 LB. |
| Material | Carbon steel. |
| Design standard | API 600. |
| Face to face | ASME B16.10. |
| Connection end | BW, Flange. |
| Test standard | API 598. |
| Package | Plywood |
| Application | The oil and gas industry |
