API 600 Bolted Bonnet Gate Valve, ASTM A216 WCB, 6 IN, 150 LB
Key Specifications / Features
Model No.: WV-231225-AGV-21 Hits: 5
Welcome to our Bolted Bonnet Gate Valve Fabrication service, where precision and quality define our valve manufacturing. Crafted in accordance with API 600 and ASME B16.34 standards, our valve is designed for optimal performance. Featuring a substantial 6-inch size (DN150) and a robust Class 150 LB (PN20) rating, our Bolted Bonnet Gate Valve is constructed from ASTM A216 WCB material.
Request a quoteTags:
Detail Information
Size: 6 Inch, DN150
Pressure: Class 150 LB, PN20
Material: ASTM A216 WCB
Standard: API 600, ASME B16.34
Feature: Wedge type gate valves, Bolted Bonnet Cast Steel Gate Valve, Welding Seat Rings Gate Valve
Applicable Standards:
Gate valves designed according to API 600, ASME B16.34
Face-to-face ASME B16.10
End Flanges ASME B16.5, ASME B16.47
Butt welding ends ASME B16.25
Inspection and test API 598
Pressure Range: ASME CL150, CL300, CL600, CL900, CL1500
Working temp: -196℃ - 650℃
Size Range: 2 - 36 Inch
End Connection: Flanged, butt weld
Body Material: ASTM A216 WCB, ASTM A217 WC6, ASTM A217 WC9, ASTM A351 CF8, ASTM A351 CF8M, ASTM A352 LCB, ASTM A352 LCC
Operation: Manual, handwheel, gear, electric, pneumatic, hydraulic
Design Description: Outside Screw and York, Bolted Bonnet and Pressure Seal, Flexible wedge, fully guided, Welding seat rings or Renewable seat rings, Rising stem and non-rising stem, Available with gear operator, Flange Ends, Butt welding Ends
Pressure: Class 150 LB, PN20
Material: ASTM A216 WCB
Standard: API 600, ASME B16.34
Feature: Wedge type gate valves, Bolted Bonnet Cast Steel Gate Valve, Welding Seat Rings Gate Valve
Applicable Standards:
Gate valves designed according to API 600, ASME B16.34
Face-to-face ASME B16.10
End Flanges ASME B16.5, ASME B16.47
Butt welding ends ASME B16.25
Inspection and test API 598
Pressure Range: ASME CL150, CL300, CL600, CL900, CL1500
Working temp: -196℃ - 650℃
Size Range: 2 - 36 Inch
End Connection: Flanged, butt weld
Body Material: ASTM A216 WCB, ASTM A217 WC6, ASTM A217 WC9, ASTM A351 CF8, ASTM A351 CF8M, ASTM A352 LCB, ASTM A352 LCC
Operation: Manual, handwheel, gear, electric, pneumatic, hydraulic
Design Description: Outside Screw and York, Bolted Bonnet and Pressure Seal, Flexible wedge, fully guided, Welding seat rings or Renewable seat rings, Rising stem and non-rising stem, Available with gear operator, Flange Ends, Butt welding Ends
