Bellow Seal Globe Valve, ASTM A105N, 1 Inch, CL 400 LB, RF

Bellow Seal Globe Valve, ASTM A105N, 1 Inch, CL 400 LB, RF

Key Specifications / Features

Model No.: WV-240304-FGBV-10 Hits: 6

Manufacturer of bellow seal globe valves constructed from Forged Steel ASTM A105N, ensuring robustness and reliability. These valves are 1 inch in size, with DN25 dimensions, rated Class 400 LB and PN63. Featuring a raised flanged end for secure installation, they are operated via a handwheel mechanism. With a reduced port design, they provide efficient flow control and are suitable for various industrial applications.

Request a quote

Detail Information

Standard: API 602, BS 5352
Material: ASTM A105N
Size: 1 Inch, DN25
Pressure: Class 400 LB, PN63
End Connection: RF
Operating: Handwheel
Test & Inspection: API 598, ISO 5208
Face to Face:  ASME B16.10
Suitable Medium: Water, Natural Gas, Oil and some corrosive liquid
Working Temperature: -29℃ – +425℃
