API 602 Bolted Bonnet Globe Valve, ASTM A105N, 1 IN, 800 LB
Key Specifications / Features
Model No.: WV-240427-AGBV-03 Hits: 0
Welcome to our Bolted Bonnet Globe Valve Plant in China, where we specialize in manufacturing high-quality valves to meet your needs. Our Forged Steel ASTM A105N Globe Valve is engineered with precision, boasting a 1-inch size and Class 800 LB rating, making it ideal for a variety of applications. Compliant with API 602 standards, it ensures reliable performance and precise flow control.
Request a quoteTags:
Detail Information
Globe valve, Carbon steel, 1 INCH, 800 LB, A105N, SW, HANDWHEEL.
Standard: API 602.
Material: ASTM A105N
Size: 1 Inch, DN25
Pressure: 800 LB, PN130
End Connection: SW.
Operation: HANDWHEEL
Face to face: MFG'S.
Test and inspection: API 598.
Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 2 Inch (DN15 - DN50).
End connection: SW, BW, Flange.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +425℃.
Standard: API 602.
Material: ASTM A105N
Size: 1 Inch, DN25
Pressure: 800 LB, PN130
End Connection: SW.
Operation: HANDWHEEL
Face to face: MFG'S.
Test and inspection: API 598.
Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 2 Inch (DN15 - DN50).
End connection: SW, BW, Flange.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +425℃.
| Product | Globe valve. |
| Nominal diameter | 1/2 Inch - 2 Inch. |
| Design temp. | Down to -29℃. |
| Design pressure | Class 150 - 2500 LB. |
| Material | Carbon Steel. |
| Design standard | API 602. |
| Face to face | MFG’S. |
| Operation | Handwheel |
| Connection end | SW, BW, Flange. |
| Test standard | API 598. |
| Package | Plywood |
| Application | The oil and gas industry |
