ASTM A351 CF8M Gate Valve, API 600, 3 Inch, Class 300 LB, RF

ASTM A351 CF8M Gate Valve, API 600, 3 Inch, Class 300 LB, RF

Key Specifications / Features

Model No.: WV-231219-AGV-07 Hits: 14

Are you looking for a reliable API 600 Gate Valve producer? Discover precision and quality with our offerings, featuring Stainless Steel ASTM A351 CF8M construction. Our 3-inch valves, designed for DN80 applications, are engineered for Class 300 LB and PN50, ensuring optimal performance. Equipped with a Rising Stem, Welded Bonnet, and Raised Flanged Ends, these valves provide durability and secure connections.

Request a quote

Detail Information

Valve description:
Gate valve, welded bonnet, solid wedge, Raised flange.
Design: API 602.
Body: ASME A182 F316
Nominal size: 2 Inch.
Nominal class: 2500 LB.
End Connection: Raised flange, ASME B16.5.
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Stainless Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flanged.
Pressure range: Class 150 - 2500 LB (PN16 - PN250).
Working temperature: -29℃ - +300℃.

Technical parameters and characteristics
Product Gate valve.
Nominal diameter 1/2 Inch - 32 Inch.
Design temp. Down to -29℃.
Design pressure Class 150 - 2500 LB.
Material Stainless Steel.
Design standard API 600, API 602.
Face to face ASME B16.10.
Connection end BW, Flange.
Test standard API 598.
Package Plywood
Application The oil and gas industry
