Welded Bonnet Gate Valve, SS ASTM A182 F316, 2 Inch, 2500 LB

Welded Bonnet Gate Valve, SS ASTM A182 F316, 2 Inch, 2500 LB

Key Specifications / Features

Model No.: WV-231219-AGV-06 Hits: 4

Explore the capabilities of our cutting-edge Stainless Steel Gate Valve Plant, delivering precision and reliability. Crafted from high-grade ASTM A182 F316 stainless steel, our 2-inch valves are engineered for excellence, boasting a robust Class 2500 LB rating. Featuring a Solid Wedge Gate and a Welded Bonnet, these valves ensure durability and optimal performance. With a Raised Flange End, our valves provide secure and stable connections, enhancing their versatility across applications.

Request a quote

Detail Information

Valve description:
Gate valve, welded bonnet, solid wedge, Raised flange.
Design: API 602.
Body: ASME A182 F316
Nominal size: 2 Inch.
Nominal class: 2500 LB.
End Connection: Raised flange, ASME B16.5.
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Stainless Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flanged.
Pressure range: Class 150 - 2500 LB (PN16 - PN250).
Working temperature: -29℃ - +300℃.

Technical parameters and characteristics
Product Gate valve.
Nominal diameter 1/2 Inch - 32 Inch.
Design temp. Down to -29℃.
Design pressure Class 150 - 2500 LB.
Material Stainless Steel.
Design standard API 600, API 602.
Face to face ASME B16.10.
Connection end BW, Flange.
Test standard API 598.
Package Plywood
Application The oil and gas industry
