ASTM A351 CF8M Ball Valve, 2 PC, 1-1/2 Inch, 3000 WOG, FNPT
Key Specifications / Features
Model No.: WV-231226-FBV-01
Hits: 141
Discover unparalleled reliability with our Double Block Bleed Ball Valve, expertly manufactured to the highest standards. Compliant with API 608, Gost, and Din specifications, this valve is engineered for optimal performance and versatility in diverse industrial applications. Featuring a sturdy 2-inch size, Class 300 LB rating, and DN50 dimensions, this valve ensures robustness and efficiency in fluid control.
$0.01In stock(Price depends upon negotiation)
Tags
Detail Information
Design Standard: API 608
Body Material: ASTM A351 CF8M, Stainless Steel
Nominal Diameter: 1-1/2 Inch, DN40
Pressure: 3000 WOG
End Connection: FNPT
Face To Face: FACTORY STANDARD
Test And Inspection: API 598
Product Range
Size Range: 1/4 - 4 Inch (DN8-DN100)
Applicable Temperature: -20℃-150℃
Main Materials: ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M
Applicable Medium: Water, Oil, Gas, Causticity Medium
Pressure Rating: 1000 WOG, 2000 WOG
Body Material: ASTM A351 CF8M, Stainless Steel
Nominal Diameter: 1-1/2 Inch, DN40
Pressure: 3000 WOG
End Connection: FNPT
Face To Face: FACTORY STANDARD
Test And Inspection: API 598
Product Range
Size Range: 1/4 - 4 Inch (DN8-DN100)
Applicable Temperature: -20℃-150℃
Main Materials: ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M
Applicable Medium: Water, Oil, Gas, Causticity Medium
Pressure Rating: 1000 WOG, 2000 WOG
| ITEM | PART | MATERIAL | ||
| 1 | Body | CF8M | CF8 | WCB |
| 2 | Ball Seat | PTFE/RPTFE/PPL | ||
| 3 | Ball | 316 | 304 | 201 |
| 4 | Body Gasket | PTFE | ||
| 5 | Cap | CF8M | CF8 | WCB |
| 6 | Stem | 316 | 304 | 201 |
| 7 | Thrust Washer | PTFE | ||
| 8 | Stem Packing | PTFE | ||
| 9 | Gland Nut | 304 | ||
| 10 | Handle | 201 | ||
| 11 | Spring Washer | 304 | ||
| 12 | Nut | 304 | ||
| 13 | Locking Device | 201 | ||
| 14 | Handle Cover | Plastic | ||
