API 602 Gate Valve, ASTM A105, 1-1/2 Inch, Class 150 LB, RF
Key Specifications / Features
Model No.: WV-231228-AGV-11 Hits: 30
Discover our distinguished API 602 Gate Valve, proudly manufactured by our reputable facility in China. Crafted from high-quality Carbon Steel ASTM A105, this 1-1/2 inch gate valve adheres to the stringent standards of API 602. With a Class 150 LB rating and DN40 specifications, our gate valve is engineered for reliable performance in diverse applications.
$0.01In stock(Price depends upon negotiation)
Request a quoteTags
Detail Information
Design: API 602.
Body: ASTM A105
Nominal size: 1 1/2 INCH.
Nominal class: 150 LB.
End Connection: Raised flange.
Face to face: ASME B16.10.
Test and inspection: API 598.
Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flanged.
Pressure range: Class 150 - 2500 LB (PN16 - PN250).
Working temperature: -29℃ - +429℃.
Technical parameters and characteristics
Body: ASTM A105
Nominal size: 1 1/2 INCH.
Nominal class: 150 LB.
End Connection: Raised flange.
Face to face: ASME B16.10.
Test and inspection: API 598.
Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flanged.
Pressure range: Class 150 - 2500 LB (PN16 - PN250).
Working temperature: -29℃ - +429℃.
Technical parameters and characteristics
| Product | Gate valve. |
| Nominal diameter | 1/2 Inch - 32 Inch. |
| Design temp. | Down to -29℃. |
| Design pressure | Class 150 - 2500 LB. |
| Material | Carbon Steel. |
| Design standard | API 602. |
| Face to face | ASME B16.10. |
| OPERATION | HANDWHEEL |
| Connection end | BW, Flange. |
| Test standard | API 598. |
| Package | Plywood |
| Application | The oil and gas industry |
