Ceramic Ball Valve, ASTM A182 F304, DN100, PN16, RF Flanged

Ceramic Ball Valve, ASTM A182 F304, DN100, PN16, RF Flanged

Key Specifications / Features

Model No.: WV-231220-FSBV-05 Hits: 5

Welcome to our Ceramic Ball Valve Plant in China, where precision and innovation converge. Our valves, featuring Stainless Steel ASTM A182 F304 construction, are meticulously designed for optimal performance. With a DN100 size, 4 Inch diameter, and Class 150 LB rating, these ball valves are engineered to meet the stringent requirements of diverse applications. Featuring a Bolted Bonnet design and RF (Raised Face) Flange Ends, our valves ensure secure sealing and connections.

Request a quote

Detail Information

On this page

Detail Infomation

Ceramic ball valve, Stainless steel, DN100, PN16, RF, FULL PORT.

Valve description:
Ceramic ball valve, bolted bonnet, raised flanged.
Design: GB/T 12224.
Body: ASTM A182 F304
Nominal size: DN100.
Nominal class: PN16.
End Connection: RF flange.
Face to face: GB/T 12221.
Test and inspection: GB/T 9092.

Product Range:
Body material: Stainless steel.
Normal diameter: 2 - 16 Inch (DN50 - DN400).
End connection: Flanged.
Pressure range: PN10-PN16.
Working temperature: -29℃ - +150℃.

Technical parameters and characteristics
Product Ceramic ball valve.
Nominal diameter 2 Inch - 16 Inch.
Design temp. Down to -29℃.
Design pressure PN10-PN16.
Material Stainless steel.
Design standard GB/T 12224.
Face to face GB/T 12221.
Connection end Flange.
Test standard GB/T 9092.
Package Plywood
Application granular media
Model Q641TC
