API 602 Ball Valve, Reduced Bore, 1/2 * 3/8 Inch, 1500 LB

API 602 Ball Valve, Reduced Bore, 1/2 * 3/8 Inch, 1500 LB

Key Specifications / Features

Model No.: WV-231220-FSBV-08 Hits: 1

As a leading Reduced Bore Ball Valve Manufacturer, we specialize in precision-engineered solutions for your fluid control needs. Our valves, crafted from high-quality ASTM A182 F316 material, adhere to API 602 standards and boast a reduced bore design. With a 1/2 * 3/8 Inch size and Class 1500 LB rating, these ball valves are engineered for optimal performance.

Request a quote

Detail Infomation

On this page

Detail Infomation

Valve description:
Ball valve, stainless steel, bolted bonnet, three-pieces, Reduced bore
Design: API 602.
Body: ASTM A182 F316
Nominal size: 1/2x3/8 Inch.
Nominal class: 1500 LB.
End Connection: RF.
OPERATION: LEVER
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW,Flange.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +300℃.

Technical parameters and characteristics
Product Ball valve.
Nominal diameter 1/2 - 32 Inch.
Design temp. Down to -29℃.
Design pressure Class 150 - 2500 LB.
Material Stainless Steel.
Design standard API602.
Face to face ASME B16.10.
OPERATION LEVER
Connection end Flange.
Test standard API 598.
Package Plywood
Application The oil and gas industry
