Cavity Free Floating Ball Valve, A351 CF8M, 10-8 IN, 150 LB
Key Specifications / Features
Model No.: WV-240103-FBV-2 Hits: 1
As a leading Cavity Free Floating Ball Valve Manufacturer, we produce high-quality valves meeting API 6D standards. Our precision-engineered valves, constructed from ASTM A351 CF8M material, come in a 10 x 8-inch size, designed for Class 150 LB and PN20 applications. Featuring a Metal Seated design, Bolted Bonnet, and Renewable Seat Ring, our valves ensure reliable performance and longevity.
Request a quoteTags:
Detail Information
Design Standard: API 6D
Body Material: ASTM A351 CF8M
Nominal Diameter: 10 Inch x 8 Inch
Pressure: Class 150 LB, PN20
End Connection: ASME B16.5 (RF & RTJ), ASME B16.25 (BW)
Face To Face: ASME B16.10, VERVO'STD
Test And Inspection: API 598, API 6D
Feature: Cavity-Free Floating Ball Valve, metal seated Cavity Free Valve, Full or Reduced Bore, Bolted Bonnet, Renewable seat rings, Metal seat or Soft seat
VERVO Cavity Free Valve is offered in 1 PC top entry body design in a wide range of carbon, stainless steel, duplex stainless steel, alloy and other special materials. It can be widely used in the applications and conditions where media cannot accumulate in the valve cavity, VERVO Cavity Free Valve is manufactured according to API 6D or API 608 Standard.
Product Range
Sizes: NPS 2 to NPS 24, DN50-DN600
Pressure: Class 150 to Class 2500 LB (PN16 – PN420)
MATERIALS: ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A105, ASTM A350 LF2, ASTM A182 F304, ASTM A182 F316, ASTM A182 F304L, ASTM A182 F316L
End Connection: RF, RTJ, or BW
Design & manufacture according to API 608, API 6D, ASME B16.34
Face-to-face according to ASME B16.10, VERVO'STD
End Connection according to ASME B16.5 (RF & RTJ), ASME B16.25 (BW)
Test &inspection according to API 598, API 6D
Also available per NACE MR-0175, NACE MR-0103, ISO 15848
Body Material: ASTM A351 CF8M
Nominal Diameter: 10 Inch x 8 Inch
Pressure: Class 150 LB, PN20
End Connection: ASME B16.5 (RF & RTJ), ASME B16.25 (BW)
Face To Face: ASME B16.10, VERVO'STD
Test And Inspection: API 598, API 6D
Feature: Cavity-Free Floating Ball Valve, metal seated Cavity Free Valve, Full or Reduced Bore, Bolted Bonnet, Renewable seat rings, Metal seat or Soft seat
VERVO Cavity Free Valve is offered in 1 PC top entry body design in a wide range of carbon, stainless steel, duplex stainless steel, alloy and other special materials. It can be widely used in the applications and conditions where media cannot accumulate in the valve cavity, VERVO Cavity Free Valve is manufactured according to API 6D or API 608 Standard.
Product Range
Sizes: NPS 2 to NPS 24, DN50-DN600
Pressure: Class 150 to Class 2500 LB (PN16 – PN420)
MATERIALS: ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A105, ASTM A350 LF2, ASTM A182 F304, ASTM A182 F316, ASTM A182 F304L, ASTM A182 F316L
End Connection: RF, RTJ, or BW
Design & manufacture according to API 608, API 6D, ASME B16.34
Face-to-face according to ASME B16.10, VERVO'STD
End Connection according to ASME B16.5 (RF & RTJ), ASME B16.25 (BW)
Test &inspection according to API 598, API 6D
Also available per NACE MR-0175, NACE MR-0103, ISO 15848
