3 Way Floating Ball Valve, ASTM A351 CF8, 4 Inch, 150 LB, RF
Key Specifications / Features
Model No.: WV-240103-FBV-05 Hits: 2
Explore our cutting-edge 3-Way Floating Ball Valve Plant featuring API 6D compliance, 4-inch size, Class 150 LB performance, and precision engineering with ASTM A351 CF8 material. Choose between full or reduced bore options, benefit from Fire Safe and Anti-Static features, and experience enhanced durability with our innovative Oversized Stem Design.
Request a quoteTags:
Detail Information
Design Standard: API 6D
Body Material: ASTM A351 CF8
Nominal Diameter: 4 Inch, DN100, 100MM
Pressure: Class 150 LB, CL150
End Connection: FLANGE RF
Face To Face: ASME B16.10
Test And Inspection: API 598
Feature: Trunnion Mounted Floating Ball Valve, Oversized stem design, Unique 4-seats design, Spring-loaded design, Fire safe design, Anti-blowout stem design, Anti-static design, ISO 5211 Mounting Pad design.
Product Range
Body Material: Standard in ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M. Other materials are available according to requirements.
Nominal Size: 1-1/2-8 Inch (DN40-DN200)
Pressure Rating: ASME Class 150 LB, Class 300 LB, DIN PN16, PN40
End Connections: RF, RTJ
Temperature Range:
Soft Seat: -20-356℉ (-29-180℃)
Metal Seat: -20-932℉ (-29-500℃)
Flanged Dimensions: ASME B16.5, EN 1092-1
Body Pressure Test: API 598
Seat Leakage Test:
Soft Seat: API 598
Metal Seat: ANSI/FCI70-2 Class V
Casting: MSS-SP-25, MSS-SP-55
Body Material: ASTM A351 CF8
Nominal Diameter: 4 Inch, DN100, 100MM
Pressure: Class 150 LB, CL150
End Connection: FLANGE RF
Face To Face: ASME B16.10
Test And Inspection: API 598
Feature: Trunnion Mounted Floating Ball Valve, Oversized stem design, Unique 4-seats design, Spring-loaded design, Fire safe design, Anti-blowout stem design, Anti-static design, ISO 5211 Mounting Pad design.
Product Range
Body Material: Standard in ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M. Other materials are available according to requirements.
Nominal Size: 1-1/2-8 Inch (DN40-DN200)
Pressure Rating: ASME Class 150 LB, Class 300 LB, DIN PN16, PN40
End Connections: RF, RTJ
Temperature Range:
Soft Seat: -20-356℉ (-29-180℃)
Metal Seat: -20-932℉ (-29-500℃)
Flanged Dimensions: ASME B16.5, EN 1092-1
Body Pressure Test: API 598
Seat Leakage Test:
Soft Seat: API 598
Metal Seat: ANSI/FCI70-2 Class V
Casting: MSS-SP-25, MSS-SP-55
