Cryogenic Gate Valve, ASTM A350 LF2, 1 Inch, Class 1500 LB
Key Specifications / Features
Model No.: WV-231225-AGV-01 Hits: 1
Introducing our high-quality ASTM A350 LF2 Cryogenic Gate Valve, meticulously crafted to meet industry standards such as API 602, BS 5352, ISO 15761, and ASME B16.34. With a compact 1-inch size (DN25) and a robust Class 1500 LB (PN250) rating, this valve is designed for optimal performance in cryogenic applications. The valve features a reliable RF Flanged End with a gasket seal, ensuring secure and leak-free operation.
Request a quoteTags:
Detail Information
Name: Forged Gate Valve
Media: Oli, Gas, Water
Size: 1 Inch, DN25
Pressure: Class 1500 LB, PN250
Material: ASTM A350 LF2
End Connection: RF Flanged
Temperature Of Media: -54℃ - 232℃
Product Range
Size: 1/4 - 4 Inch, DN8-DN100
Pressure: Class 150-800 LB, 1500 LB, 2500 LB
Standard: API 602, BS 5352, ISO 15761, ASME B16.34
Material: Carbon Steel,
Power: Manual, Pneumatic, Solenoid, Electrical Actuated
Media: Oli, Gas, Water
Size: 1 Inch, DN25
Pressure: Class 1500 LB, PN250
Material: ASTM A350 LF2
End Connection: RF Flanged
Temperature Of Media: -54℃ - 232℃
| Item | A350 LF2 |
| Certification | CE,TS,ISO9001,ISO14001,ISO18001,API |
| Connection form | Welding RF Flanged |
| Body material | Low Temperature A350 LF2 |
| Seal material | Gasket |
| Feature | Easy disassembly and assembly |
Product Range
Size: 1/4 - 4 Inch, DN8-DN100
Pressure: Class 150-800 LB, 1500 LB, 2500 LB
Standard: API 602, BS 5352, ISO 15761, ASME B16.34
Material: Carbon Steel,
Power: Manual, Pneumatic, Solenoid, Electrical Actuated
