API 6D Ball Valve, ASTM A216 WCB, 2PC, 12 Inch, 150 LB, RF

API 6D Ball Valve, ASTM A216 WCB, 2PC, 12 Inch, 150 LB, RF

Key Specifications / Features

Model No.: WV-240326-TMBV-01 Hits: 1

We are a reputable manufacturer of API 6D Ball Valves, offering a two-piece design crafted from ASTM A216 WCB. Our valves are designed for 12-inch pipelines (DN300), rated Class 150 LB (PN20), and feature a raised flange end for easy installation. With a full port design and gear box operation, our ball valves ensure efficient flow control and reliable performance in various industrial applications.

Request a quote

Detail Information


Ball valve, carbon steel, bolted bonnet, TWO-pieces, GEARBOX

Design: API 6D
Materials: ASTM A216 WCB
Size: 12 Inch, DN300
Pressure: Class 150 LB, PN20
End Connection: RF
Operation: Gear
Face to face: ASME B16.10
Test and inspection: API 598

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flange.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +429℃.
