Dual Plate Check Valve, API 594, ASTM A351 CF8, 6 IN, 150 LB
Key Specifications / Features
Model No.: WV-231221-WCV-03 Hits: 44
Experience unparalleled reliability with our Dual Plate Check Valve, expertly produced to meet the highest standards. This valve boasts a Double Flanged End design, adhering to API 594 standards, making it an ideal choice for diverse applications. Crafted from premium Stainless Steel ASTM A351 CF8, this 6-inch valve operates seamlessly in Class 150 LB and PN20 environments.
$0.01In stock(Price depends upon negotiation)
Request a quoteTags
Detail Information
Valve description:
Double Flanged Dual Plate Check Valve, Stainless steel.Design: API 594.
Body: ASTM A351 CF8
Nominal size: 6 Inch.
Nominal class: 150 LB.
End Connection: FLANGE.
Face to face: ASME B16.10/API 594.
Test and inspection: API 598.
Product Range:
Body material: Stainless Steel.
Normal diameter: 6 - 32 Inch (DN15 - DN800).
End connection: Flange (RF, RTJ).
Pressure range: Class 150 - 900 LB (PN16 - PN100).
Working temperature: -29℃ - +300℃.
Technical parameters and characteristics
| Product | Double Flanged Dual Plate Check Valve. |
| Nominal diameter | 6 Inch - 32 Inch. |
| Design temp. | Down to -29℃. |
| Design pressure | Class 150 - 900 LB. |
| Material | Stainless Steel. |
| Design standard | API 594. |
| Face to face | ASME B16.10/API594 |
| Connection end | Flange (RF, RTJ) |
| Test standard | API 598. |
| Package | Plywood |
| Application | water, oil and gas. |
| HS CODE | 8481804090 |
