ASTM A216 WCB T Type Strainer, BS EN 12516, DN80, PN16
Key Specifications / Features
Model No.: WV-240408-TTS-01
Hits: 80
Manufactured from Carbon Steel ASTM A351 WCB, this T Type Strainer is designed for reliability. With a DN80 size, PN16 rating, and 3-inch diameter, it accommodates various mesh sizes including 40, 80, 100, and customized options. Compliant with EN 12516 and EN 1092-1 standards, it ensures efficient filtration in industrial applications.
$0.01In stock(Price depends upon negotiation)
Tags
Detail Information
T type-Strainer, Carbon steel, DN80, WCB.
Standard: BS EN 12516.
Material: ASTM A351 WCB
Size: DN80, 3 Inch
Pressure: PN16, Class 150 LB
End Connection: EN 1092-1
Test and inspection: API 598.
Product Range:
Body material: Carbon steel.
Normal diameter: 1/2 - 24 Inch (DN15 - DN600).
End connection: EN 1092-1.
Pressure range: PN10-PN100.
Working temperature: -29℃ - +425℃.
Standard: BS EN 12516.
Material: ASTM A351 WCB
Size: DN80, 3 Inch
Pressure: PN16, Class 150 LB
End Connection: EN 1092-1
Test and inspection: API 598.
Product Range:
Body material: Carbon steel.
Normal diameter: 1/2 - 24 Inch (DN15 - DN600).
End connection: EN 1092-1.
Pressure range: PN10-PN100.
Working temperature: -29℃ - +425℃.
| Product | Y-Strainer. |
| Nominal diameter | 1/2 Inch - 24 Inch. |
| Design temp. | Down to -29℃. |
| Design pressure | PN16 . |
| Material | Carbon Steel. |
| Design standard | BS EN 12516. |
| Connection end | EN 1092-1. |
| Test standard | API 598. |
| Package | Plywood |
| Application | The oil and gas industry |
| Face to face | EN 558-1 |
| Mesh | 40, 80, 100 and customized |
