ASTM A105N Swing Check Valve, API 622, 624, 3/4 Inch, 800 LB

ASTM A105N Swing Check Valve, API 622, 624, 3/4 Inch, 800 LB

Key Specifications / Features

Model No.: WV-231221-ASCV-08 Hits: 3

Elevate your fluid control systems with our meticulously crafted ASTM A105N Swing Check Valve, designed to meet industry-leading standards including API 622, API 624, API 602, and BS 5352. This valve, featuring a 3/4-inch size (DN20), is optimized for Class 800 LB and PN130 environments, ensuring versatility across various applications.

Request a quote

Detail Information

Design Standard: API 602, BS 5352, API 622, API 624
Body Material: ASTM A105N
Nominal Diameter: 3/4 Inch, DN20
Pressure: Class 800 LB
End Connection: SW Flange
Face To Face: Factory STD
Test And Inspection: API 598
Feature: Flanged Class 800, SS check valve, flanged swing check valve

Item Check Valve
Certification ISO9001, ISO14001, ISO18001, TS, CE
Model number H61Y-800LB-DN20
Port Size 3/4 Inch
Structure type lift /swingcheck valve
Pressure 800 LB
Temperature -29 - 429DEGREE
Connection form Flanged
Material Stainless Steel
Feature Easy disassembly

Product Range

Size: NPS 1/2 Inch to NPS 4 Inch
Pressure: Class 800 LB to Class 2500 LB
Design: API 602, ASME B16.34
