API 6D Metal Seated Ball Valve, ASTM A351 CF8, 12 IN, 600 LB
Key Specifications / Features
Model No.: WV-240103-TMBV-13 Hits: 2
Discover unparalleled performance with our Metal Seated Trunnion Mounted Ball Valve. Engineered with precision, this valve boasts a 12-inch size, Class 600 LB rating, API 6D compliance, and utilizes ASTM A351 CF8 material. With a DN300, PN100 specification, RF Flange End, and innovative Cavity Pressure Relief Design, our valve ensures optimal functionality and reliability in diverse applications.
Request a quoteTags:
Detail Information
Design Standard: API 6D
Body Material: ASTM A351 CF8
Nominal Diameter: 12 Inch, DN300, 300MM
Pressure: Class 600 LB, CL600
End Connection: Flange RF
Face To Face: ASME B16.10
Test And Inspection: API 598
Feature: True bidirectional design and wide temperature range, Cavity pressure relief design, Trunnion ball design, Single Piston seat rings, Double piston design in option, Optional double block and bleed design, Splined stem design, Emergency sealant injection design, Optional drain plug device, Several alternatives of soft and metal seats, Optional purge device, Fire safe design, Anti-static device, ISO 5211 Mounting Pad design.
Product Range
Body Material: Standard in ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M. Other materials are available according to requirements.
Nominal Size: 2-24 Inch (DN50-DN600)
Pressure Rating: Class 150 LB, Class 300 LB, Class 600 LB, Class 900 LB, Class 1500LB, Class 2500 LB on request.
End Connections: RF, RTJ
Temperature Range:
Soft seat: -320℉-482℉ (-196℃-250℃)
Metal seat: -320℉-932℉ (-196℃-500℃), the higher temperature on request
Face-to-face Dimensions: ASME B16.10
Flanged Dimensions: ASME B16.5
Body Pressure Test: ASME B16.34, API 598, API 6D
Seat Leakage Test:
Soft seat: ASME B16.34, API 598, API 6D
Metal seat: ANSI/FCI70-2 Class V in standard, Class VI in option.
Casting: MSS-SP-25, MSS-SP-55
Fire Safe Design: Certificated according to API 607, API 6FA
Body Material: ASTM A351 CF8
Nominal Diameter: 12 Inch, DN300, 300MM
Pressure: Class 600 LB, CL600
End Connection: Flange RF
Face To Face: ASME B16.10
Test And Inspection: API 598
Feature: True bidirectional design and wide temperature range, Cavity pressure relief design, Trunnion ball design, Single Piston seat rings, Double piston design in option, Optional double block and bleed design, Splined stem design, Emergency sealant injection design, Optional drain plug device, Several alternatives of soft and metal seats, Optional purge device, Fire safe design, Anti-static device, ISO 5211 Mounting Pad design.
Product Range
Body Material: Standard in ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M. Other materials are available according to requirements.
Nominal Size: 2-24 Inch (DN50-DN600)
Pressure Rating: Class 150 LB, Class 300 LB, Class 600 LB, Class 900 LB, Class 1500LB, Class 2500 LB on request.
End Connections: RF, RTJ
Temperature Range:
Soft seat: -320℉-482℉ (-196℃-250℃)
Metal seat: -320℉-932℉ (-196℃-500℃), the higher temperature on request
Face-to-face Dimensions: ASME B16.10
Flanged Dimensions: ASME B16.5
Body Pressure Test: ASME B16.34, API 598, API 6D
Seat Leakage Test:
Soft seat: ASME B16.34, API 598, API 6D
Metal seat: ANSI/FCI70-2 Class V in standard, Class VI in option.
Casting: MSS-SP-25, MSS-SP-55
Fire Safe Design: Certificated according to API 607, API 6FA
