Pressure Reducing Desuperheating Valve, ASTM A182 F11, 3 IN
Key Specifications / Features
Model No.: WV-240724-CTV-04 Hits: 2
As a specialized Pressure Reducing Desuperheating Valve, our factory offers a robust solution for precise control of pressure and temperature in various fluid systems. These valves feature an angle body design that enhances flow dynamics and minimizes pressure drop. Manufactured from premium materials such as ASTM A182 F11, F22, and F91, they are available in sizes ranging from 3 to 22 inches and classes from 150 to 4500 pounds, catering to a wide array of industrial requirements.
Request a quoteTags
Detail Information
Product Name: Low-medium Application Control Valve
Body Type: Globe/Angle
Sizes: 3-22 Inch
Pressure Ratings: Class 150-4500 LB
Materials: ASTM A182 F11, ASTM A182 F22, ASTM A182 F91
Bonnet Style:
• Bolted bonnet (up to Class 1500)
• Pressure seal bonnet (Class 2500 and over)
Actuator Type: Diaphragm, Piston, Hydraulic, Electric
Seat Leakage Class: ANSI FCI 70-2 Class IV and V
Spray Nozzle Type: Self-introducing steam atomising type
Temperature Setting: Saturated temperature +6 deg. C or more
Temperature Detector Distance: 6m from outlet connection or more in accordance with specification
Feature:
• Close control of pressure and temperature: Flexible plant systemization and well-conditioned steam save energy and reduce costs in your control system.
• Simplified piping arrangement: Reduces components, shortens the pipeline, and eliminates auxiliary steam lines, saving energy and costs.
• Easy maintenance: Fewer components and a virtually wear-free valve seat and plug extend maintenance intervals.
• Improved environment: Noise reduction and elimination of valve vibration ensure safe operation and a quieter environment.
Body Type: Globe/Angle
Sizes: 3-22 Inch
Pressure Ratings: Class 150-4500 LB
Materials: ASTM A182 F11, ASTM A182 F22, ASTM A182 F91
Bonnet Style:
• Bolted bonnet (up to Class 1500)
• Pressure seal bonnet (Class 2500 and over)
Actuator Type: Diaphragm, Piston, Hydraulic, Electric
Seat Leakage Class: ANSI FCI 70-2 Class IV and V
Spray Nozzle Type: Self-introducing steam atomising type
Temperature Setting: Saturated temperature +6 deg. C or more
Temperature Detector Distance: 6m from outlet connection or more in accordance with specification
Feature:
• Close control of pressure and temperature: Flexible plant systemization and well-conditioned steam save energy and reduce costs in your control system.
• Simplified piping arrangement: Reduces components, shortens the pipeline, and eliminates auxiliary steam lines, saving energy and costs.
• Easy maintenance: Fewer components and a virtually wear-free valve seat and plug extend maintenance intervals.
• Improved environment: Noise reduction and elimination of valve vibration ensure safe operation and a quieter environment.
