Swing Flex Check Valve, ASTM A995 4A, 8 Inch, 900 LB, BW End
Key Specifications / Features
Model No.: WV-240104-ASCV-10 Hits: 1
As a dedicated Swing Flex Check Valve fabricator, we adhere to industry standards with API 6D and BS 1868 compliance. Our valves, featuring a size of 8 inches, DN200, and constructed from ASTM A995 4A material, operate seamlessly at Class 900 LB and PN150 pressure levels. The valves are designed with flexibility, offering a choice between a Bolted Cover or a Pressure Seal Cover, ensuring reliable performance in diverse applications.
Request a quoteTags:
Detail Information
Design Standard: API 6D, BS 1868
Body Material: ASTM A995 4A
Nominal Diameter: 8 Inch, DN200
Pressure: Class 900 LB, PN150
End Connection: ASME B16.5 (RF & RTJ), ASME B16.25 (BW)
Face To Face: ASME B16.10
Test And Inspection: API 598
Feature: Butt Welded Swing Flex Check Valve, Bolted Cover or Pressure Seal Cover
Product Range
Sizes NPS 2 to NPS 36 Inch
Pressure: Class 150 to Class 2500 LB
MATERIALS: Available in Casting ASTM A216 WCB, ASTM A217 WC6, ASTM A217 WC9, ASTM A350 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A995 4A, ASTM A995 5A, ASTM A995 6A), Alloy 20, Monel, Inconel, Hastelloy
DESIGN FEATURES: Full or Reduced Bore
End: RF, RTJ, or BW
Design & manufacture according to API 6D, BS 1868
Face-to-face according to ASME B16.10
End Connection according to ASME B16.5 (RF & RTJ), ASME B16.25 (BW)
Test & inspection according to API 598
Also available per NACE MR-0175, NACE MR-0103
Body Material: ASTM A995 4A
Nominal Diameter: 8 Inch, DN200
Pressure: Class 900 LB, PN150
End Connection: ASME B16.5 (RF & RTJ), ASME B16.25 (BW)
Face To Face: ASME B16.10
Test And Inspection: API 598
Feature: Butt Welded Swing Flex Check Valve, Bolted Cover or Pressure Seal Cover
Product Range
Sizes NPS 2 to NPS 36 Inch
Pressure: Class 150 to Class 2500 LB
MATERIALS: Available in Casting ASTM A216 WCB, ASTM A217 WC6, ASTM A217 WC9, ASTM A350 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A995 4A, ASTM A995 5A, ASTM A995 6A), Alloy 20, Monel, Inconel, Hastelloy
DESIGN FEATURES: Full or Reduced Bore
End: RF, RTJ, or BW
Design & manufacture according to API 6D, BS 1868
Face-to-face according to ASME B16.10
End Connection according to ASME B16.5 (RF & RTJ), ASME B16.25 (BW)
Test & inspection according to API 598
Also available per NACE MR-0175, NACE MR-0103
