Pressure Sustaining Valve, DN200, PN25, ASTM A351 CF8, RF
Key Specifications / Features
Model No.: WV-240108-CTV-14 Hits: 2
Provider of Pressure Relief Sustaining Valve: This high-performance valve, designed according to CJ/T 167 and CJ/T 219 standards, is crafted with precision from robust Stainless Steel ASTM A351 CF8 material. With a substantial size of 8 inches (DN200) and a PN25 pressure rating (equivalent to Class 300), it excels in pressure relief and sustaining applications.
Request a quoteTags:
Detail Information
Product: Pressure Relief Valve, Pressure Sustaining Valve
Size: DN200
Pressure: PN25
Body: ASTM A351 CF8
Trim: SS 304
Performance standard:
Quality assurance: IS0 9001
Design: CJ/T 167, CJ/T 219
Structure Length: CJ/T 167, GB/T 12221
Test Standard: GB/T 13927
Connection: RF Flange
500X Pressure Relief Sustaining Valve consists of a main valve, pilot valve, and needle valve, ball valve, micro filter and pressure gauge to form a hydraulic control takeover system. Using hydraulic automatic operation, it can be used as a pressure relief valve and a pressure sustaining valve. When used as a pressure relief valve, it can maintain the pressure of the water supply line below the set safety value and maintain the water supply pressure upstream of the main valve. Its working principle is that when the pilot valve is adjusted to the pressure relief state, the water flows to the outlet through the needle valve, the main valve control room, the ball valve A the pilot valve and the ball valve B, and the main valve is in the open state at this time. When the inlet pressure exceeds the safety value set by the pilot valve, the pressure relief pilot valve will automatically open, and part of the water will be released through the ball valve C to relieve the pipeline pressure. Widely used in high-rise buildings, living areas and other water supply network systems and urban water supply projects.
Size: DN200
Pressure: PN25
Body: ASTM A351 CF8
Trim: SS 304
Performance standard:
Quality assurance: IS0 9001
Design: CJ/T 167, CJ/T 219
Structure Length: CJ/T 167, GB/T 12221
Test Standard: GB/T 13927
Connection: RF Flange
500X Pressure Relief Sustaining Valve consists of a main valve, pilot valve, and needle valve, ball valve, micro filter and pressure gauge to form a hydraulic control takeover system. Using hydraulic automatic operation, it can be used as a pressure relief valve and a pressure sustaining valve. When used as a pressure relief valve, it can maintain the pressure of the water supply line below the set safety value and maintain the water supply pressure upstream of the main valve. Its working principle is that when the pilot valve is adjusted to the pressure relief state, the water flows to the outlet through the needle valve, the main valve control room, the ball valve A the pilot valve and the ball valve B, and the main valve is in the open state at this time. When the inlet pressure exceeds the safety value set by the pilot valve, the pressure relief pilot valve will automatically open, and part of the water will be released through the ball valve C to relieve the pipeline pressure. Widely used in high-rise buildings, living areas and other water supply network systems and urban water supply projects.
